AMARAN PT1C

1-Foot RGBWW Battery-Powered LED Pixel Tube

CREATE YOUR FLOW

The amaran PT1c is an ultra-portable 1-foot battery-powered pixel tube for creators and filmmakers. As amaran’s first-ever pixelated tube light, it features multiple pixels, RGBWW color quality, Sidus Link app control, and no-hassle mounting solutions, allowing you to unleash new creative possibilities.

DESIGNED FOR CREATORS

The PT1c shines as an effects, fill, eye light, and so much more. Whether used for practical lighting backgrounds, producing unique lighting effects for long-exposure photography, creating linear reflections over intricate sets for product cinematography, or adding visual interest to stylized music videos and commercials, the PT1c grants you the freedom to get creative and bring your lighting designs to life.

PERFECT PIXEL CAPABILITIES

With 4 lighting zones that can be independently controlled, the PT1c’s pixel capabilities introduce new and exciting avenues to the amaran family and outshine other lights with a new layer of effects. Use its 7 pre-programmed Pixel FX to create some truly unique and dynamic pixelated effects across its multiple pixels and take your creations to the next level.

COLOR ACCURATE

amaran consistently delivers stellar color quality with its RGBWW LED chipset, and the Pixel Tubes are no different. Adjust the hue, saturation, and intensity of your pixel light with white point CCT tunability from 2,700K to 10,000K with full plus/minus green controls. And with a CRI of 95, TLCI of 98, and Tungsten SSI of 85, you can be sure that the Pixel Tubes will elevate your productions with accurate colors.

BUILT-IN BATTERIES

The PT1c is powered by a removable 9.6Wh Lithium-ion battery for up to 70 minutes of run time, and can be charged via USB-C for absolute ease of use. Unlike the high-capacity battery grips of the amaran T2c and amaran T4c, the integrated batteries can improve your workflow on-set by granting you the flexibility of placing or hiding the LED Pixel Tubes virtually anywhere.

READY-MADE MOUNTING SOLUTIONS

For enhanced versatility, the PT1c’s rotatable end caps can be independently swiveled with 180 degrees of rotation to ensure that it is always in the perfect position. And with built-in magnets and integrated 3/8-16in screw threads on each end cap, creating interesting visuals and set pieces have never been easier.

ADVANCED CONTROLS

With the power of the Sidus Link Bluetooth app, you can control all of your Aputure and amaran lights in a scene, activate stunning lighting effects, and ensure that the Pixel Tubes are always up to date. For more advanced console controls, the new amaran USB-C to DMX Adapter* unlocks DMX control while simultaneously charging your pixelated tube light, making your workflow even more efficient and seamless.

* amaran Type-C to DMX Adapter with Type-C Input sold separately.

CONTROL YOUR CREATIONS

For creators who want an extra touch of lighting control and to eliminate spill from the PT1c, you can attach a collapsible 45º light control grid* via hook-and-loop straps to hone the quality of the light to perfection. The Pixel Tubes can also be left bare with its wide 180° beam angle, giving you more coverage in your shot design.

* 45º Fabric Light Control Grid for amaran PT1c sold separately.

Technical Specifications

CCT

2,700K - 10,000K

CRI (@5,600K)

95

TLCI (@5,600K)

98

CQS (@5,600K)

96

SSI (D56)

75

SSI (Tungsten)

85

TM-30 RF (@5,600K)

92

TM-30 RG (@5,600K)

100

Max Power Output

6W

Max Power Draw

8W

Pixel Mapping

4 Pixels

Lumens

370lm

Beam Angle

180º

Charging Input

USB Type-C

Battery Voltage

3.7V

Battery Capacity

2600mAh, 9.6Wh

Battery Runtime

Approx. 70 Mins @ 100% Output

Charge Time

Approx. 110 Mins (5V/2A)

Approx. 95 Mins @ 75% Output

Operating Temperature

-10ºC ~ 40ºC / 14ºF ~ 104ºF

Approx. 139 Mins @ 50% Output

Firmware Upgradeable

Sidus Link

Approx. 369 Mins @ 10% Output

Wireless Operating Range (Bluetooth)

≤80m / ≤262.5ft

Screen Type

TFT

IP Rating

IP20

Cooling Method

Passive Cooling

View all

View Less

Dimensions

Fixture

φ42 x 300mm / φ1.65 x 11.81in

USB-C Charging Cable Length

1.1m / 43.31in

Weights

Fixture

315g / 0.69lbs

What's in the Box

amaran PT1c

USB Type-C Charging Cable (1.1m)

Carrying Pouch

Photometrics

CCT0.5m1.0m
2,700K325 lux / 30 fc87 lux / 8 fc
3,200K331 lux / 31 fc88 lux / 8 fc
4,300K342 lux / 32 fc91 lux / 8 fc`
5,600K359 lux / 33 fc95 lux / 9 fc
6,500K355 lux / 33 fc94 lux / 9 fc
7,500K339 lux / 31 fc89 lux / 8 fc
10,000K313 lux / 29 fc83 lux / 8 fc
Red240 lux / 22 fc64 lux / 6 fc
Green337 lux / 31 fc92 lux / 9 fc
Blue74 lux / 7 fc20 lux / 2 fc

Downloads


Firmware Release Date

amaran PT - Firmware Update V2.9 - On Sidus Link 02/27/2023

Certifications
